Rimoldi | 263-264-268

Available in the following subclasse:

263-06 for underwear and knitwear and bathing suits. Flatbed top covering chainstitch  machine for assembling and topstitching operation

263-10 for underwear and knitwear flatbed top covering machine. For hemming operations

263-16 / 263-17 for underwear and knitwear. Flatbed covering chainstitch machine for ribbon application with and without elastic insertion

263-30 / 263-31 for underwear and knitwear. Flatbed top covering machine for lace application on underwear and lingerie

263-38  for underwear and knitwear. Special flatbed top covering machine for assembling operations of gussets on underwear garments of reinforced stripes on knitwear

263-46 for underwear and knitwear. Top covering chainstich machine for assembling and topstitching operations

264-00 double locked chainstitch  machine. For assembly seams on light, medium and heavy fabrics

264-04 single thread chainstich basting machine. For the ready-to-wear clothing industry, dye houses and making up various articles

264-10 for hemming towels and similar articles

264-11 for the underwear and lingerie industry. Double chainstitch machine for attaching and inserting elastic, metering rollers and auxiliary feed roller

264-22 for making decorative gathering on ladies and children dresses and various other articles

264-38 for knit-underwear. Double chainstitch machine for attaching reinforcing strips on knit-underwear

264-38-0ML-02 / 264-38-9ML-01 for attaching decorative strips on track suit sleeves and trousers

268-00-2MD-19 for assembly seaming with overlapping of two pieces and for hemming operations



Video
264-04-1MB-02

Single thread chainstich basting machine for medium and heavy ready-to-wear clothing industry and dye houses

264-11-2RK-01

2 needles flatbed machine for hemming the waistband of women’s knitted or fleece panties by inserting a flat elastic in the hem. Equipped with dosing rollers and toothed feeding rollers

264-00-1MR-38

Chainstitch machine for assembly seams of medium-heavy fabrics. Fixed trimming knives. Adjustable seam allowance up to 5mm. With differential. Suitable for straight or wide-curved seams

264-04-1MB-03

Single-needle chainstitch 1-thread machine, suitable for closing nylon warp-knit pieces in preparatory dyeing operations

264-38-0ML-01

Machine for application of ornamental stripes to trousers and sports suit sleeves

263-16-2MD-01/19500

Flatbed machine 2 needles mm 3,5 for the application of the collarettes

264-00-1CN-32

One needle flat bed machine for gloves production madeof interlock fabrics. Equipped with trimming  knives for a 2 mm cut from the seam. Knives can also be excluded when not necessary and special little and articulated foot for doing small curves and seams



264-00-1CN-GUANTI
264-11-4EL-11

4 needle machine 28,5 mm double locked chainstich without differential feed. For hemming at the waist of mens. trunks, pyjiamas trousers shorts and similar garments in woven fabric, simoultaneosly attaching elastic outside the waist hem or inserting it inside hem. The elastic is stitched down by the needles along the seam
